  • ABOUT 3D

    Without buying any costlier software,Start 3D Printing now !

    .
    Anybody who are having high end photosmart Digital Printer, or Inkjet Printer or Plotter, or high end offset print machine, can do this job..

    To earn Extra In thousands. Print it ... Paste it and deliver it.

    .
    Just get done 2D to 3D Design conversion of your 2D image from me and print it on your own print machine,Flip,Animation or 3D images.

    .
    About 3D

    .
    3D Image is about using large area thin lens array,with corrugation similar in looks to corrugated packing paper sheet, to optically separate and present different imges from a complex interlaced image pint to two different eyes and use this phenomenon for viewer to perceive 3D & or Flip,which are two basic effects..
    .
    All other effects like animation,zoom,morph(and you can create with your imagination many more effects) etc.are extension of basic flip effect..
    .
    .

    Various components of 3D product and the process used to make them require: optical precision with respect to alignment and registration of these components..
    And hence it is not buying something, as simple as photoshop like software, and use it to edit the image at one place and print anywhere..
    It is about understaning the technical details of 3d process and then using your graphic art skills to generate breath taking amazing 3D print products. .

    And hence you must call me , whenever you can get time,realize the complexity and see some sample products to know its capability.

  • Home

    • ALSO PROVIDE WEB DEVELOPMENT SERVICES

  • F.A.Q.

    Let me introduce my self, I Niranjan Giri giving Consultancy * Software * Training Freelance Design Development Service for 3D lenticular products, Web designing and Raw Material Provider for the same. I am in field of 3D Lenticular Printing since last 20 Years.

    How It Works

    If you want finished 3d products from me. Upload your design, Get a 3D preview, Order it & have it shipped worldwide.

    What finished product will cost me?

    From 75 paisa per sq, inch to RS:5/- per Squinch depends upon quantity and type of lens i.e. acrylic, pet or pp. Plus Sampling cost.

    What is sampling cost?

    Please See the Costing Page.

    HOW IT WORKS

    If you want to get done print 3d products on your own print machine, & want me to give you only designing service. Upload your design, Get a 3D preview, Order it & have it shipped worldwide.

    What will be cost of redy to print Soft Copy ?

    Its depends upon work and take time consuming to convert simple 2D design to 3D. Can not give you approximate estimate except your machine has been tested for dot gain & blanket pressure with given test copy.

    What should I do If I want to print lenticular images on my own print machine ?

    First of all You have to purchase Test file from me. Make CTP Plates from given file and get done print on best quality 300gsm card sheets.Match that print with given lens pieces.with whichever lens you satisfied with the result,that lens will be the best for your print machine.

    Is it necessary to print test file ?

    Yes, because only after seeing your print result I will come to get an Idea about density of Ink and pressure of printing Blankets. If your machine registration is good then definitely you can enter in field of 3D Lenticular Printing.

    What will be Test Copy cost?

    RS:5,250/- plus GST 18% rs.945/- = 6,195/-,per lens type. Five types of lens: 40/50 LPI,75 lpi pet & pp,100 LPI pet and pp. If Interested pl. deposit said amount in my bank account and inform me for the same on cell. 09867100177

    Learn how to paste print with lens for RS:2500/-.

    Learn how to operate 3D Software: RS: 1,00,000/- only.

    What will raw material cost ?/

    In India imported 75 LPI lens are available in 20" x 28" size for RS:100/- to 120/- plus GST. and Indian 75 LPI lens are available in 20" x 28" size for RS:55/- to 65/- plus GST. If you get done Import from China Its will cost you about RS:50/- to 60/- per sheet.

    As I am giving consultancy service Sorry I will not be able to give you more answers then given here. For rest inquiries either get my consultancy service @ RS:5000/- plus GST 18% RS: 900/- = RS: 5,900/-,

    or buy test copy per lens type @ RS:5250/-plus GST 18% RS.945/- = RS.6.195/- to test your print machine.

    For getting more details You can mail to

    studio3dimage@gmail.com,or log on to www.digisignsindia.com

    Mob:09867 100 177

    E & O. E.

  • Home

    • ALSO PROVIDE WEB DESIGNING SERVICES

  • Products

    Products Products
    Business Cards Art Murals
    Bookmarks Artists' Posters
    Book Covers Art Postcards
    Buttons Booth Signage
    Event Badges Posters
    Event Mailer Signage
    Inserts POP Displays
    Postcards Movie Posters
    Scale Patti / Rulers In Door Displays Boards
    Danglers / Hangtags Pre-Show Mailers
    Handouts Personal Photographs

    Popular Sizes : Offset Printing

    .50 mm x 75 mm (approx. 2 inches X 3 inches)
    Up to 75 mm x 100 mm (approx. 3 inches X 4 inches)
    Up to 100 mm x 150 mm (approx. 4 inches X 6 inches)
    Up to 142 mm x 94 mm (approx. A6)
    Up to 194 mm x 142 mm (approx. A5)
    Up to 290 mm x 200 mm (approx. A4)
    Up to 300 mm x 400 mm (A3)

  • Home

  • Gallary

    2D TO 3d

    Flip (2in1)

    Other Effects

  • Home

    • ALSO PROVIDE WEB DESIGNING SERVICES

  • SERVICES

    Digital Sampling time is 2-3 days depending on the complexity of the primary material.
    .
    Production time - 7-10 days.
    .
    OFFSET PRINTING on a lenticular lens We will make a sample for you before printing offset!
    .
    The minimum print order of 200 sheets (330x480) The sealed sheet format is 330x480 mm. into which you can place smaller images.,
    .
    In this format, you can place as many products as fit in a sealed format. The whole format can be used, or .

    for example, 2 images 240x220, or 4 images 240x160, or 18 types of pocket calendars 70x100 mm. etc...,
    .
    On the sheet, for example, you can fit with trimming about 20 types of magnets 60x90 mm,.
    i.e. having printed a circulation of 200 sheets, 20 kinds of magnets of 200 pieces can be made from this. each kind..
    It must be borne in mind that the lenses are oriented along the narrow side (parallel to size 330) and this can affect the layout of the layouts on the printed sheet..
    .
    The larger the quantity, the cheaper! The direction of the lens is on the short side where you can place your smaller 3D dimensions or animations.
    .

  • Home

    • ALSO PROVIDE WEB DESIGNING SERVICES

    Costing



  • COST

    		•
    Products Price
    Personal Family Photographs,00 ( 2 copies. 5" X 7" ) Rs. 1,000.00
    Learn How to Paste,How to Cut. Rs. 2500.00
    CMYK TEST COPY For Digital / Inkjet Printer Rs. 3,250.00
    CMYK TEST COPY For Offset Printers Rs. 5,250.00
    Lern How to Operate Lenticular Software Per Effect. Rs. 50,000.00
    Digital Sampling for 2D to3D effect,Size:6" X 8" on 40/50/75 lpi lens Rs. 3,250.00
    Digital Sampling for any other effect,Size:5" X 7"on 40/50/75 lpi lens Rs. 4,000.00
    Conversion cost from any format to psd layers file Rs. 2,000.00
    Correction Modification cost each and every time Rs. 1,000.00
    Finished product cost per s.inch 75 lpi pp. Rs.1.20
    Finished product cost per s.inch 75 lpi pet. Rs.1.40
    Only Soft Copy Cost without Sampling For 10 to 25 LPI Lens,
    Per running inch at longer side of an Image Any One Effect,(Minimum cost RS.9,000,per image)    		 Rs.500
    Only Soft Copy Cost without Sampling For 30 to 60 LPI Lens,
    Per running inch at longer side of an Image 2d to 3d effect,(Minimum cost RS.9,000,per image)    		 Rs.1,800
    Only Soft Copy Cost without Sampling For 30 to 60 LPI Lens,
    Per running inch at longer side of an Image any other effect(any one) i.e.2 in 1 flip,Zomm,Animation etc.,(Minimum cost RS.9,000,per image)    		 Rs.2,250
    Only Soft Copy Cost without Sampling For 70 to 100 LPI Lens,
    Per running inch at longer side of an Image 2d to 3d effect,(Minimum cost RS.9,000,per image)    		 Rs.2,250
    Only Soft Copy Cost without Sampling For 70 to 100 LPI Lens,
    Per running inch at longer side of an Image any other effect(any one) i.e.2 in 1 flip,Zomm,Animation etc.,(Minimum cost RS.9,000 per image)    		 Rs.2,700
    75 lpi pp. sheet 20" x 28", 100 sheets minimum packing Rs.9,000
    75 lpi pet. sheet 20" x 28", 100 sheets minimum packing Rs.10,000
    50 lpi per. sheet 20 x" 28" ,100 sheets minimum packing Rs.14,000
    50 lpi pet. sheet 20" x 28", 100 sheets minimum packing Rs.32,000
    pl.note: Material cost is given for getting general idea only,Actual cost may change time to time.
    Plus add Digital sampling cost, Punching cost, Back side Gumming cost, GST 18% and Courier cost.
    and whatever any other requirements cost Whichever you need to get your finished product.

  • Home

    • ALSO PROVIDE WEB DESIGNING SERVICES

  • Guidelines

    THE BASICS Files are usually supplied as Photoshop, but for simple flip images TIFF or JPEG can also be used. Resolution: 300dpi
    .
    Bleed: Please be sure to include a 1/8''bleed (except for 3D images which require 1/8'' bleed on top and bottom and 1 inch bleed on left and right).
    Color: Files should be supplied as CMYK. If they are supplied as RGB there will be a shift in color as they are converted..
    Hard Copy: Whenever possible, please provide a hard copy of your artwork for our reference. This helps avoid any possible confusion or delay in processing your job..
    .

    SOME MORE TIPS
    .
    Avoid very thin lines at they tend to break up and look pixilated underneath the lenticular lens. Text should be at least 12 point San Serif font..
    Whenever possible,avoid solid color backgrounds (especially white) and instead use textured backgrounds with color..
    Avoid strong contrast between elements of the image that will change. In other words, avoid having elements change from black to white as this will cause ghosting between the images..
    .
    Animations can either happen as the viewing angle changes left to right or up/down. The fact is that up/down images simply work better so unless you are using your lenticular as a display piece that people will be walking past, we recommend up/down animations. This does not affect the artwork supplied. .
    .
    All lenticular images can be classified into two types of effects: 3D and Animation..
    .
    ANIMATION These can be anything from a flip (an animation that simply changes between Image 1 and Image 2), a Zoom (an image that gets progressively larger in each frame) to a motion image which animates through a large series of frames. No need to distinguish between these; they are all animations. .
    .
    Tips For Animated Images If possible, keep at least the background constant in each image. The more that is the same in each frame, the more clearly the parts that change will stand out.Less is more! When choosing the number of frames to appear in the image keep in mind that the more frames that are used, the less clearly you will see each one. This can help with something fluid like a baseball swing but can hurt if the frames are meant to be completely distinct. Just remember, more frames usually means more ghosting. 3D These images do not change. They appear to show depth between the elements of the image and look the same from all viewing angles..
    .
    TIPS FOR 3D IMAGES .
    .
    Image must be supplied as layered Photoshop file with each element of the image on its own completed layer. The more elements that appear in the image, the more depth information there will be for the viewer. Depth is only relative between objects so make sure there are enough elements to compare.
    .
    .Add texture to the background layer as this will also create depth information. The lenses must run vertically in a 3D image and horizontally in an animating image. Keep any changing images low contrast. This one is important! Avoid having any part of the image change from black to white. If you have a black dog walking across a white background, the black ink from the first frame will not disappear into the white background and you will see the cat at all positions all the time. Avoid having the parts of the image that are animating contrast in color and when possible keep the foreground lighter than the background. .
    .
    Up/Down works better than Left/Right Its a fact! In lenticular animation, images that animate when tilted up/down work better than animations that animate left/right. In this case works better means that you will see each frame separated more clearly from every other frame. Keep text size above 10 point Avoid fine lines and small text. Fine lines will break up under the lens creating a pixelated look that will render your text unreadable..
    .
    When creating a 3D lenticular, make sure there is texture in each element.Depth only exists relative to another element. To understand that some element is in front of another element, both elements need to show themselves. The best way to do this is to make sure that all elements (especially backgrounds) have texture..
    .
    A solid color with no pattern to it does not create good depth information. When creating a 3D lenticular, complete each element on a separate layer. Imagine an image featuring a dog in front of a wall. If we pull that dog forward, you will see around his edges and see the cutout of a dog left in the wall. This is why it is important to complete each layer; failing to do so leaves a gap when the elements are separated onto different planes..
    .
    In the end, your customer is going to see your message animating or standing out in 3D and say Wow, cool ..
    Thats the point of producing a lenticular: to create excitement and convey a message.
